The QS-LV provides a large reduction of supply-borne noise and hum. Supply noise is especially problematic for single-ended amps, but the QS-LV will make an SE amp as quiet as a well-balanced push-pull amp. Quiet that Champ, Valve Jr., GA-3/4/5/6 and all the clones.

Push-pull amps benefit from QS-LV's hum reduction, too. Switching to triode mode in most amps causes an increase in hum. With QS-LV installed the supply will be QUIET and so will both triode and pentode operating modes. Tame the noise of your clipped plexi, Trainwreck, Komet or other non-master-volume amp.

Supply voltages up to 450Vdc are accommodated, and amplifier power up to 120Wrms. On-board current limiting protects both QS-LV and your amp.

Proper heat sinking is required. In most amps, the chassis will suffice as the heat sink. In amps over 100W, or that are cathode biased for 30W and over, it is best to add a fan to cool the chassis. An aluminum heat sink is also a good idea on larger amps.

Installation of QS-LV will bring your amp one step closer to achieving the noise performance of London Power's amp line.

If you are building a stand-alone preamp, achieve world-class performance by adding the QS-LV to the PSU-PRE.

PCB dimensions: 1.9 x 1,4", 48 x 36mm

Kit includes notes with installation tips + layout and schematic diagrams of the kit.
